TYN 105F Mounted Short Connector | Cable Mounted Short Plugs SS 105
The number of contacts in TYN 105F plug is 2~40.it replace Fischers SS 105 core series connector,
small size, blind insertion and high life,micro-circular high-density connector,Sample available,large stock,short lead times
1, Brief introduction:
Connector assures a reliable connection with corresponding Fischer plugs and Plugs of other companies of the same type making it,widely used in audio equipment, data acquisition, aerospace and other occasions.
2, Main features:
3, Construction and size:
4, Technical data sheet:
| Mechanical life | >3000 |
| Vibration | frequency 10-20000Hz, acceleration 147m/s2, ≤1um instantaneous impact: acceleration 490m/s2, ≤1um instantaneous |
| Working temperature | -55 ° C ~ + 145 ° C |
| Relative humidity | up to 95° at 40°C |
| Protection level | IP68 |
| Connector type | Plug, male Contacts |
| Number of positions | 2~40 pin |
| Termination | Solder |
| Fastening type | Push-pull |
| Orientation | semi-circular positioning |
| Shell material | Brass |
| Shell finish | Chrome |
| Shell color | Silver or Black |
| Contact material | Brass |
| Contact finish-mating | Gold |
| Contact color | Gold |
| Insert material | PPS |
| Cable opening | 8.5mm~11.5mm |
5, Why choose us
- We can provide OEM/ODM service and cable assembly solution.
- better quality at a reasonable price
- Lower your cost, cheap cable assembly offer, at least save your 30%-50% cost (100% compatible and work well)
- Our factory has 9 years experience and strong and professional research and development capabilities.Advanced development and management, comprehensive R&D testing and highly automatic production line make our products high reliability and high performance.
- Our company have passed ISO9001, and also got CE,CB,and SGS certification
- large stock, short lead times, easy to buy.
6, Choosing tips:
If you have purchased fischer connector or connector like this type and know the original model, please tell us. We will directly offer you our corresponding one.
If you don’t know much about the connector, please make choose according the following factors:
- the use of the environment, indoors or outdoors, waterproof or not;
- the panel hole size, to select the appropriate plug and socket of right dimension;
- the current-voltage and the realization of the function, to determine the cores;
- select the appropriate clamp diameter and sheath;
- according to the actual needs of different angles of the keys, to determine semi-circular positioning
